The Mini Industrial Ethernet Switch combines two 10/100/1000Base-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ support and four 1000Base-FX SFP slots, providing flexible copper and fiber connectivity for industrial networks. Designed for industrial control and Ethernet ring network applications, it features redundant dual 9–56VDC power inputs for reliable operation and greater flexibility in industrial power systems.
The switch supports Full/Half-Duplex operation, Auto-Negotiation, Auto MDI/MDIX, IEEE 802.3az Energy Efficient Ethernet, Jumbo Frames, and Store-and-Forward switching for stable and efficient data transmission. Its compact fanless aluminum housing, IP40 protection, DIN-Rail mounting, and wide -40°C to +80°C operating temperature range make it suitable for demanding industrial environments, including power, water infrastructure, rail transit, traffic monitoring, renewable energy, building automation, and other critical industrial applications.
- 2 × 10/100/1000Base-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ support
- 4 × 1000Base-FX SFP slots for fiber optic connectivity
- Supports Full/Half-Duplex operation
- Auto-Negotiation and Auto MDI/MDIX
- Supports IEEE 802.3az Energy Efficient Ethernet (EEE)
- Supports IEEE 802.3/802.3u/802.3ab/802.3z/802.3x
- Store-and-Forward switching
- Supports redundant dual 9–56VDC power input
- Supports 9K-byte Jumbo Frames
- Compact, fanless aluminum housing with IP40 protection
- DIN-Rail installation
- Wide operating temperature range: -40°C to +80°C (-40°F to +176°F)
- Designed for industrial Ethernet, fiber networking, Ethernet ring networks, transportation, power, renewable energy, and automation applications
